Proven & Cost-Effective

The most widely deployed LED packaging method, offering strong performance and value across pixel pitches.

Lightweight Construction

Individual SMD lamp packages simplify installation and reduce structural load for wall-mounted or suspended displays.

Wide Pixel Pitch Range

Available from P1.25 through P5 and beyond, from close-viewing rooms to large-format signage.

Easy Component-Level Repair

Individual LED lamp beads can be resoldered or replaced on-site, keeping maintenance low and downtime short.

High Refresh Rate

Refresh rates from 1,920Hz to 3,840Hz deliver flicker-free output for broadcast and video conferencing.

Broad Compatibility

Works with all mainstream LED control systems, with no proprietary lock-in.

Vivid Colour Reproduction

Brightness up to 1,000 nits ensures vibrant, high-clarity visuals.

Seamless Cabinet Design

Die-cast aluminium cabinets deliver a smooth, uniform display surface.

Versatile Deployment

Suited for corporate lobbies, retail environments, control rooms, and broadcast studios.

Product Technology : SMD (Surface-Mounted Device)
Pixel Pitch : 1.25 / 1.53 / 1.86 / 2.0 / 2.5 / 3.0 / 4.0 mm
Standard Module Size : 320 × 160 mm
Cabinet Material : Die-cast Aluminum
Cabinet Size : 640 × 480 mm
Refresh Rate : ≥ 1920 Hz (up to 3840 Hz available)
Brightness : 600 – 1,000 nits
Viewing Angle (H/V) : 160° / 160° or 140° / 140°
Contrast Ratio : ≥ 4,000:1
Maintenance Method : Front & Rear Access
Input Voltage : AC 100–240 V, 50/60 Hz
Operating Temperature : −20°C to +60°C
Operating Humidity : 10%–90% RH
Lifespan : ≥ 100,000 hours
Control System : Synchronous (NovaStar, Colorlight, Linsn)
