Simplicity and scale
A Windows-based solution that quickly scales and deploys across your collaboration spaces.
The Q-SYS RoomSuite Collaboration Bar and expansion devices provide a scalable AV solution for standard small-to-large meeting spaces. This Windows-based solution features built-in audio, video, and supports Microsoft Teams Rooms and bring-your-own-meeting conferencing*. Includes a touch panel for control and allows for optional table microphones for extended audio coverage.
Simplified Hardware
The Q-SYS RoomSuite Collaboration Bar is an integrated Windows-based device with a built-in compute. It features four high-resolution cameras, a 16-element microphone array and integrated loudspeakers. The included 10.9-inch touchscreen controller simplifies meeting management and AV bridging, while up to four optional table microphones provide flexible audio coverage with mute sync.
Simplified Configuration (not programming)
The Q-SYS RoomSuite Collaboration Bar was designed to be up and running in minutes (without Q-SYS Designer Software). Devices are plug-and-play, providing integrated meeting and device control plus room-ready audio that greatly reduces setup time. The web-based configuration tool lets users make additional changes to ensure the best performance in any space.
Simplified Registration to Q-SYS Reflect
A few simple steps connects your Q-SYS RoomSuite Collaboration Bar to systemwide remote monitoring and management via Q-SYS Reflect. Just scan the QR code located on the exterior packaging or bar to access a web-based interface for easy configuration.
Simplified System-wide Management
The Q-SYS RoomSuite Collaboration Bar connects to Q-SYS Reflect, a cloud-based monitoring and management tool that ties together every Q-SYS system across your high-performance workplace, and communal areas, providing system administrators with real-time actions and insights. Coming soon, Q-SYS Reflect Plus will enable quicker scalability using presets, an easy way to save and deploy configurations of the Q-SYS RoomSuite Collaboration Bar at scale.
SYSTEM COMPONENTS
| Model | Q-SYS RoomSuite Collaboration Bar | ||
|---|---|---|---|
| System Details | |||
| Product type | Collaboration bar with integrated cameras, loudspeakers and microphone array | ||
| Operating system | Windows 11 IoT Enterprise (x64) | ||
| Power | 19V/19.5V DC Input (power supply included) | ||
| Peripheral support | Up to 4 Q-SYS RoomSuite Table Microphones for the Collaboration Bar (sold separately) | ||
| Controls & indicators |
• Microphone status LED indicators • Camera privacy screen |
||
| Compute & performance | |||
| Processor | Intel® i5 1340P | ||
| Memory | 16 GB RAM | ||
| Storage | 256 GB | ||
| Graphics | Intel® UHD Graphics (13th Gen) | ||
| Camera | |||
| Camera quantity | 2x wide-angle, 2x telephoto | ||
| Resolution | 4x 50 MP image sensors | ||
| Zoom | 8x hybrid zoom | ||
| Privacy | Automatic lens shutter | ||
| Field of view | |||
| Camera | Horizontal | Vertical | Diagonal |
| Wide camera | 125° | 50° | 130° |
| Telephoto camera | 42° | 32° | 52° |
| Audio | |||
| Configuration | Stereo (2.0) | ||
| Power Output | 20 W max per loudspeaker (40 W max total) | ||
| Max SPL | 89 dB SPL (+/- 3 dB) @ 1W / 0.5 m | ||
| Frequency Range | 80 Hz – 20 kHz | ||
| Microphone | |||
| Microphone array | 16-element microphone array | ||
| Pickup range | Up to 33 ft (10 m) | ||
| Sensitivity | -36 dBFS | ||
| Sample rate | 48 kHz | ||
| Frequency range | 100 Hz – 10.5 kHz, +/-3 dB | ||
| Content sharing | |||
| HDMI | Local sharing 1080p30 | ||
| Wireless & Networking | |||
| Wi-Fi | Wi-Fi 6 (2×2 MIMO) | ||
| Wi-Fi bands | 2.4 GHz + 5 GHz | ||
| RJ45 ports (4) |
• 1x 1Gbps Ethernet port for internet connection • 1x USB-CAT PSE PoE+ Ethernet port for RS-CB-CTL11 Controller I/O • 1x 1Gbps Ethernet port for RS-CB-CTL11 Controller BYOM function • 1x 1Gbps PSE PoE Ethernet port for RS-CB-TM Expansion Table microphones |
||
| Video I/O | |||
| HDMI inputs | 4k60 capable, 1080p30 supported for ingest | ||
| HDMI outputs | 3x total, 2x supported, (4K60 capable CEC supported) | ||
| USB I/O | |||
| USB ports |
• 1x USB-A 3.0 • 1x USB-A 2.0 (under right endcap) |
||
| Bundle | |||
| Physical | |||
| Collaboration Bar product dimensions (L × W × H) | 36.1 × 4.7 × 4.3 in (918 × 120.5 × 109 mm) | ||
| Collaboration Bar product weight | 11.8 lbs (5.4 kg) | ||
| Controller product dimensions (L × W × H) | 10.39 × 6.9 × 3.3 in (264 × 175.6 × 84.1 mm) | ||
| Controller product weight | 2.2 lbs (1 kg) | ||
| Included Accessories |
• 1x Power adapter • 1x 5 ft (1.5 m) AC cable (country-specific) • 2x 6.56 ft (2 m) HDMI cables • 1x 6.56 ft (2 m) Ethernet cable • 2 × 24.6 ft (7.5 m) Ethernet cable • 1x 5 ft (1.5 m) USB-C cable • 1x Wall Mounting components (for the Collaboration Bar) • 2x Table Mounting rubber feet (for the Collaboration Bar) |
||
| Environmental & safety | |||
| Storage temperature range | -4° to 140°F (-20 to 60°C) | ||
| Storage humidity range | 10% to 90% | ||
| Operating temperature range | 32° to 95°F (0° to 35°C) | ||
| Operating humidity range | 5% to 85% | ||
